製品詳細
起源の場所: 江蘇省、中国
ブランド名: Hongbao
証明: DNV,PED,ISO,TUV,LR
モデル番号: HB-TI
支払いと送料の条件
最小注文数量: 200kg
価格: negotiable
パッケージの詳細: 耐航性のある合板ケース梱包。
受渡し時間: 50日以内に
支払条件: D/P、L/C、D/A、L/C、ウェスタンユニオン
供給の能力: 800MT/年
材料：: |
Gr1、Gr2、Gr3、Gr7、Gr9、Gr12 |
証明書：: |
DNV,PED,ISO,TUV,LR |
厚さ:: |
0.4-10mm |
OD:: |
10-114MM |
長さ：: |
100〜15000mm |
形：: |
ラウンド |
材料：: |
Gr1、Gr2、Gr3、Gr7、Gr9、Gr12 |
証明書：: |
DNV,PED,ISO,TUV,LR |
厚さ:: |
0.4-10mm |
OD:: |
10-114MM |
長さ：: |
100〜15000mm |
形：: |
ラウンド |
| Standard | ASTM B337, ASTM B338, ASTM B861, ASTM B862 |
| Grade | Gr1, Gr2, Gr7, Gr9, Gr12 |
| Dimension | OD*WT*L (10-114)*(0.4-10)*(100-15000)mm |
| Manufacturing method | Cold rolled |
| Condition | Annealed(M) |
| Features | Light weight, excellent corrosion resistivity, strongly heat-resistance, high strength. |
| Inspection | Ultrasonic testing, Hydrostatic testing, Flattening testing, visual surface inspection, Dimensional inspection, tensile properties inspection and Chemical elements analysis. |
BASIC TENSION DATE
Grade | Tensile Strength, min | Yield Strengh 0.2% offset Yleld | Elongation in 2in or 50mm Min% | ||||
Ksi |
Mpa | Min | Max | ||||
| Ksi | Mpa | Ksi | Mpa | ||||
| 1 | 35 | 240 | 20 | 138 | 45 | 310 | 24 |
| 2 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
| 7 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
| 9A | 125 | 860 | 105 | 725 | / | / | 10 |
| 9B | 90 | 620 | 70 | 483 | / | / | 15c |
| 12 | 70 | 483 | 50 | 345 | / | / | 18c |
| A. Properties for cold-worked and stress-relieved B. Annealed. C. Solution treated | |||||||
Chemical Component og Material:
Grade1- Unalloyed titanium.
Grade2- Unalloyed titanium.
Grade7- Unalloyed titanium plus 0.12 to 0.25% palladium.
Grade9- Titanium alloy (3% aluminum, 235% vanadium.
Grade12- Titanium alloy (0.3% molybdenum, 0.8% nickel.
Size Tolerance:
| Standard | OD Tolerance | WT Tolerance |
ASTM B338
| ＜25.4mm, ±0.102mm |
±10% |
| 24.4-38.1mm ±0.127mm | ||
| 38.1-50.8mm ±0.152mm | ||
| 50.8-63.5mm ±0.178mm | ||
| 60.3-88.9mm ±0.254mm | ||
ASTM B861 | 3.2-3.8mm -0.794/+0.397mm |
±12.5% |
| 38-102mm ±0.794mm | ||
| 102-203mm 0.794/+1.588mm |
